Product Information :

Product Name:
Linkan Asia L&K อะไหล่สำหรับซ่อมบำรุงเตียงผู้ป่วยในโรงพยาบาล
Product Category:   การบริการต่าง ๆ, การซ่อมบำรุง
Product Sub-Category:   Linkan Asia L&K
Brand:   Linkan Asia L&K
Product Type :   สินค้า, ผลิตภัณฑ์
Short Description :   Linkan Asia L&K อะไหล่สำหรับซ่อมบำรุงเตียงผู้ป่วยในโรงพยาบาล รีโมทเตียงไฟฟ้ายี่ห้อ L&K รุ่น HB 33-00 เตียงผู้ป่วย,เตียงไฟฟ้า LINKAN L&K





Linkan Asia Co. is a prominent Actuator manufacturer. Our R&D teams have years of professional experience in electronics, electrical engineering, and mechanical knowledge. Combining theory with practical experience in our profession, we have devoted our attentions to the design, development and manufacture of the automatic control systems like linear actuators, control boxes, controllers, lifting columns, and well as many other products.



We are always developing new products with our customer’s current and future needs and wants in mind.

Our motorized hospital beds, dental chairs and the patient moving rack were first utilized in medical rehabilitation facilities but now our products are enjoyed in the ordinary household as well as in offices and recreational sports areas.

We maintain very strict quality standards for our products; our after-sale services are impeccable and consistent.


Our expertise in renovation, excellence and leadership in the industry is guaranteed at Linkan Asia Co. We want to help you achieve a higher standard of living.





















  Linear Actuators

  LA25






LA25 is a quiet, handy, speedy and elastic Actuator, design in variety applications. Such as those in furniture, care, rehabilitations and fire control window fields; it is available with a wide range of options and safety protections.


Features:

- 12V / 24V DC permanent magnet motor
- Thrust 1000N, Typical Speed 10~25mm/s
- Aluminum Alloy housing protects motor and gear
- Strong wear and corrosion resistant stainless steel inner tube
- Elegant and compact design with small installation dimensions.
- Steel piston rod eye
- Duty Cycle: Max. 10% or 2 min. / 18min. in continuous use
- Ambient temperature:+5ºC to+ 40ºC
- Protection class: IP56
- Color: Silver Grey
- Cable Length 100cm


  Linear Actuators

  LA26 (New Product)






LA26 is a quiet, handy, speedy and elastic Actuator, design in variety applications. Such as those in furniture, care, rehabilitations and fire control window fields; it is available with a wide range of options and safety protections.

Features:

- 12V / 24V DC permanent magnet motor
- Output 35W
- Thrust 1500N, Typical Speed 10~25mm/s
- Aluminum Alloy housing protects motor and gear
- Strong wear and corrosion resistant stainless steel inner tube
- Elegant and compact design with small installation dimensions.
- Steel piston rod eye
- Duty Cycle: Max. 10% or 2 min. / 18min. in continuous use
- Ambient temperature:+5ºC to+ 40ºC
- Protection class: IP56
- Color: Silver Grey
- Cable Length 100cm




  Linear Actuators

  LA27 (New Product)






LA27 is an extreme powerful actuator, its intensified inner structure with new mechanism makes the thrust up to 10000N. It is suitable for the equipment of medical and rehabilitation which require powerful thrust actuator.

Features:

- 24V DC permanent magnet motor
- Thrust: 8000~10000N
- Limited switches built-in
- Strong wear and corrosion resistant stainless steel inner tube
- Steel piston rod eye
- Zinc alloy back fixture
- Duty cycle: Max. 10% or 2 min./ 18 min. in continuous use
- Ambient temperature: +5ºC to+ 40ºC
- Protection class: IP54
- Color: Grey-white

  Linear Actuators

  LA28 (New Product)






LA28 is a new designed actuator for variety application, the streamline designed on its figure and its intensified inner structure with new mechanism makes the performance stable and quiet, it is suitable for being used in the furniture and equipment of beauty, care, medical and rehabilitation.



Features:
- 24V DC permanent magnet motor
- Thrust: 2000~8000N
- Limited switches built-in
- Metal inner structure to protect motor and gears
- Duty cycle: Max. 10% or 2 min./ 18 min. in continuous use
- Ambient temperature: +5ºC to+ 40ºC
- Protection class: IP54
- Color: Grey-white

  Linear Actuators

  LA29






LA29 has an elegant and streamlined design which is suitable to use in furniture, rehabilitation and sports applications. LA29 is developed and focused on the push applications; it has a very strong structure and can be mounted with CB03. Most importantly, it has a very competitive price and can be easily installed.

Features:

- 24V DC permanent magnet motor
- Up to 6000N in push. LA29 is applicable to in push but it is not applicable to in pull
- Built-in limit switches (not adjustable)
- Stroke length: 10cm~25cm
- Aluminum material tunnel outside, exquisite and classical
- Elegant and compact design; small installation dimension
- Duty cycle: Max. 10% or 2 min. continuous usage followed by 18 min. rest
- Ambient temperature:+5ºC to+ 40ºC
- Color: Black
- Protection Class: IP 54

Options:

- Can be mounted with CB03
- Gray color optional









  Linear Actuators

  LA33






LA33 has an elegant and streamline design suitable to use in furniture, rehabilitation and sports sectors. LA33 is developed for push applications; it has a very strong construction and competitive price.



Features:

- 24V DC permanent magnet motor
- Thrust 4000N~ 6000N
- Built-in end stop signal switches (not adjustable)
- Stroke length: 5cm~30cm
- The outside tunnel is aluminum material, exquisite and classical
- Elegant and compact design; small installation dimension
- Duty cycle: Max. 10% or 2 min./ 18 min. in continuous use
- Ambient temperature: +5ºC to +40ºC
- Color: Black

Options:

- Back fixture position 0º or 90º
- Box color: Gray-White (Min. order 1,000 pcs)
- Three types for rod eye: Groove+Round . Oval . Round
- T-Din Jack Plug for mounting with CB06 or combining LA30
- Spline device
- Protection class: IP51
- Can install Hall Sensor function (Contact R & D department of LINKAN A/C first)




  Linear Actuators

  LA32






LA32 is a very quiet and powerful actuator designed for a variety of applications, such as those in furniture, care or rehabilitation fields; it is available with a wide range of options and safety protections.



Features:

- 24V DC permanent magnet motor
- Thrust 1500N~6000N; Speed 3.0~16.7mm/s
- Built-in limited switches (not adjustable)
- High-strength plastic housing protects motor and gear
- Scratch-resistant and wear-resistant powder painted outer tube
- Strong wear and corrosion resistant stainless steel inner tube
- Elegant and compact design with small installation dimensions
- Steel piston rod eye
- Zinc alloy back fixture
- Duty cycle: Max. 10% or 2 min./ 18 min. in continuous use
- Ambient temperature: +5ºC to +40ºC
- Protection class: IP54
- Color: Black

Options:

- LA32 can be fitted with a brake for increasing self-lock effect
- Safety nut
- Protection class: IP66 (not for wash tunnels)
- Reed-Switch
- Quick-Release
- Back stretch sleeve fixture (For only Quick-Release function)
- 0.2/ 0.4m coiled cable with DIN or Jack plug
- Back fixture position 0º or 90º
- Steel groove piston rod eye
- Fast motor
- Color: Gray-White (Min. order: 1,000 pcs)
- Can install Hall Sensor function (Contact R & D department of LINKAN A/C first)




  Linear Actuators

  LA31






LA31 is a very quiet and powerful actuator designed for a variety of applications, such as those in furniture, care or rehabilitation fields; it is available with a wide range of options and safety protections.

Features:
- 24V DC permanent magnet motor
- Thrust up to 6000N; Speed 3.0~16.7mm/s
- Built-in limited switches (not adjustable)
- High-strength plastic housing protects motor and gear
- Scratch and wear-resistant powder painted outer tube
- Strong wear and corrosion resistant stainless steel inner tube
- Elegant and compact design with small installation dimensions
- Steel piston rod eye
- Zinc alloy back fixture
- Duty cycle: Max. 10% or 2 min./ 18 min. in continuous use
- Ambient temperature:+5ºC to+ 40ºC
- Protection class: IP54
- Color: Black

Options:
- LA31 can be fitted with a brake for increasing self-lock effect
- Safety nut
- Protection class: IP66 (not for wash tunnels)
- Reed-Switch
- Quick-Release Q
- Back stretch sleeve fixture (For only Quick-Release function)
- 0.2/ 0.4m coiled cable with DIN or Jack plug
- Back fixture position 0º or 90º
- Steel groove piston rod eye
- Fast motor
- Color: Gray-White (Min. order: 1,000 pcs)
- Can install Hall Sensor function (Contact R & D department of LINKAN A/C first)






  Linear Actuators

  LA30-RF






LA30-RF wireless controlled motor, massage motor can be used with two groups for leisure at home bed type, easy installation method and structure, to create life more fun and comfortable sleep environment.

Features:
- Overall structure is simple, easy to install
- Low noise
- structural strength, impact resistance
- mains voltage: AC 220-240V 50Hz; AC100-120V 60Hz
- up to 10% duty cycle, or continuously for 6 minutes per hour
- withstand ambient temperature range: +5ºC to+ 40ºC
- Protection class: IP20
- low power consumption, higher power 4000NX2
- special safety buckle slider design
- With wireless hand controller, tie him down for no manipulation.
- Color: white
Options:
- can be used with the other two groups massage motor, strong and weak massage can be adjusted, as more functionality options, please contact our technical department.


  Linear Actuators

  LA30






LA30 can be applied in various home living bed, its easy installation and simple structure create enjoyments for living with cozy sleeping environment.

Features:
- Simple external structure and easy installation
- Low noise
- Solid structure and durable feature
- Main power voltage: AC 220-240V 50Hz;AC100-120V 60Hz
- Duty cycle max. 10% or 6 min. rest per hour in continuous use
- Ambient temperature: +5?C to +40?C
- Standard protection level: IP20
- Low electricity consumption, high thrust 4000NX2
- Special safety button for sliding
- Color: Black

Options:
- Can add one-axis or two-axes additional actuators for elevating or tilting of bed
- Can use 9V alkaline battery as spares when there are shortage of interior electricity, but only work for downward movements
- Can combine with LA33 ( Max. 2 pcs) for elevating and tilting of bed







  Linear Actuators

  LA39






LA39 is a quiet, handy, speedy and yet powerful Actuator, design in variety applications. Such as those in furniture, care and rehabilitations fields; it is available with a wide range of options and safety protections

Features:
- 24V DC permanent magnet motor
- Thrust 1000N~3000N, Typical Speed 5.0~30.0mm/s
- High-Strength Plastic housing protects motor and gear
- Strong wear and corrosion resistant stainless steel inner tube
- Elegant and compact design with small installation dimensions.
- Steel piston rod eye
- Duty Cycle: Max. 10% or 2 min. / 18min. in continuous use
- Ambient temperature:+5ºC to+ 40ºC
- Protection class: IP54
- Color: Black

Options:

- Protection class: IP66(not for wash tunnels)
- 0.2/0.4m coiled cable with DIN or Jack plug
- Back fixture position 0ºor 90º
- Steel groove piston rod eye
- Can Install overload protection circuit inside



  Linear Actuators

  LA37 (NEW)






LA37 is an actuator with robust spindle, unique overload device and strong motor. The actuator structure is a patent design suitable for the field of hospitals, cares, and rehabilitation. When the power is off or the motor break down, the actuator can be operated with manual crank. Besides, the installation is much easier. The manual and electrical dual operation is a feature of LA37.



Features:

- 24V DC permanent magnet motor
- Thrust from 4000N to 6000N
- Robust structure design with easy installation
- Electrical and manual dual operation
- Built-in overload structure design
- Low noise
- Duty cycle: Max. 10% or 2 min./ 18 min. in continuous use
- Ambient temperature: +5ºC to +40ºC
- Protection class: IP31
- Color: Black
- Used with CB07-S control box

Options:

- Housing color: Gray-White (Min. Order: 1,000 pcs)
- Crank




  Linear Actuators

  LA36






LA36 is an actuator with robust spindle, unique spindle and strong motor. The actuator structure is unique design suitable for the field of sofa chairs, leisure chair and etc. Besides, the installation is much easier.

Features:

- 24V DC permanent magnet motor
- Thrust from 4000N to 6000N
- Robust structure design with easy installation
- Low noise
- Duty cycle: Max. 10% or 2 min./ 18 min. in continuous use
- Ambient temperature:+5ºC to+ 40ºC
- Protection class: IP54
- Color: Black


  Linear Actuators

  LA35






LA35 has strong housing and special outer shape with strong structure. It has complete functions and can be used in high-loaded environment. For example, dental chairs, hospital beds, sport equipment, etc.. Its applications can be widely used.

Feature :

- 24V permanent magnet motor
- Thrust 4000N ~ 8000N
- Built-in end stop signal switches (not adjustable)
- Stroke length : 10cm , 15cm , 20cm
- The outside tunnel is aluminum material; inside tunnel is stainless material with low friction and high quality.
- Elegant and compact design; small installation dimension
- Duty cycle: Max. 10% or 2 min./ 18min. in continuous use
- Ambient temperature: +5?C to +40?C
- Color : Black

Option :

- Back fixture position 0? or 90? and can choose strong-type solid tailstock
- Reed switch can combine CB05 , CB24 , CB28
- Rod eye can be groove
- Protection level : IP66
- Can install Hall Sensor function (Contact R & D department of LINKAN A/C first)



  Linear Actuators

  LA34






LA34 is a quiet, handy and speedy Actuator, design in variety applications. Such as those in furniture, care and fire window; it is available with a wide rang of options and safety protections

Features:

- 12V/24V DC permanent magnet motor.
- Thrust 1200N, Typical speed 17~28 mm/s
- Plastic housing protects motor and gear.
- Strong wear and corrosion resistant stainless steel inner tube.
- Elegant and compact design with small installation dimensions.
- Duty cycle: Max. 10% or 2 min. / 18min. in continuous use .
- Ambient temperature: +5ºC to +40ºC
- Protection class: IP56
- Color: Black/ Gery-white













































  Control Boxes

  CB20






CB20 is a control box with multi-functions, which can control up to 4 actuators and one LED light. It's designed for operating tables and ICU beds. It's ideal for vast medical applications.

Features:
- Max. for 4 actuators. Actuator types: LA29, LA31, LA32, LA33 , LA34 , LA35, LA38, LA39 (with Jack Plug)
- Mains voltage: 220-240/ 100-120V AC; 50-60Hz
- Match with ACPM
- Dual output voltage (Low load: Low voltage; High load: High voltage)
- Compact high power toroidal transformer ensures low power consumption and low electromagnetic emission
- DIN socket for handset HB5A and HB6A
- Replaceable straight power line
- Duty cycle: Max. 10% or 6 min. continuous use followed by 1 hour not in use
- Ambient temperature: +5ºC to+ 40ºC
- Protection class: IP54
- Color: black or gray-white
- Can be mounted with BA16

  Control Boxes

  CB21






CB21 is a multi-function control for operation table, it operates with HB16L+C01( Back light series) handset and ACPM42, it has memory, return (CPR) and button lock functions. In order to make more accurate position, CB21 must work with actuators which are equipped with Hall sensor motor.

Features:
- Max. for 4 actuators. Actuator type: LA28, LA31, LA32, LA33, LA35(equipped with Hall sensor motor and 5 cores DIN plug)
- Mains voltage: AC220-240V, 50Hz/ 100-120V, 60Hz
- 100W compact high power toroidal transformer ensures low power consumption and low electromagnetic emission.
- All channels have electronic overload protection (EOP) device.
- DIN socket for HB16L+C01 and ACPM42
- Replaceable straight cable.
- Duty cycle: MAX. 10% or 6 min. continuous use followed by 1 hour not in use.
- Ambient temperature: +5ºC to+ 40ºC
- Protection class: IP54
- Color: Gray-white
- Can be mounted and connected with BA16 or BA18 battery.

Options:
- Battery back-up: battery sets BA16 (Lead-Acid battery) or BA18 (Li-ion battery)
- Class 1 earth connection
- Mains fuse can be replaced from outside.
- Protection class: IP66(not allowed being in wash tunnels)
- Switching power transformer

  Control Boxes

  CB18(NEW)






CB18 is a multi-function control box that can connect up to 5actuators. Most design for the operation bed , ICU bed and multi-function bed etc. The special design for power display, the lock and return function is the standard equipment makes it ideal for medical instruments applications

Features:
- Max. for 5 actuators. Actuator type: LA31, LA32, LA33 (with Jack Plug)
- Mains voltage: 220-240/ 100-120V AC; 50-60Hz
- Dual output voltage (Low load: Low voltage; High load: High voltage)
- Compact high power toroidal transformer ensures low power consumption and low electromagnetic emission
- DIN socket for handset HB5M
- Exchangeable mains cable
- Duty cycle: Max. 10% or 6 min./ 1 hour in continuous use
- Ambient temperature: +5ºC to+ 40ºC
- Protection class: IP54
- Color: Black
- Can be mounted with BA16
- The Battery has a Warning for low Voltage
- The return and lock function
- Handset insert improperlyl or loose with warming buzzer

  Control Boxes

  CB17






CB17 is a low voltage control box that can control up to 4 actuators. A series of built-in safety and other options make it ideal for vast medical and industrial applications.

Features:
-Max. for 4 actuators. Actuator type: LA31, LA32, LA33 , LA34 , LA39 (with Jack Plug)
-Mains voltage: 220-240/ 100-120V AC; 50-60Hz
-Dual output voltage (Low load: Low voltage; High load: High voltage)
-Compact high power toroidal transformer ensures low power consumption and low electromagnetic
emission
-All channels have electronic overload protection (EOP) device
-DIN socket for handset HB8X, HB3X, HB5X,HB7X ,ACP or FS
-Fixed type mains cable
-Duty cycle: Max. 10% or 6 min. continuous use followed by 1 hour not in use
-Ambient temperature:+5ºC to +40ºC
-Protection class: IP54
-Color: Black
-Can be mounted with BA16
-The Battery has a "warning signal" for low voltage
-Mains fuse can be replaced from outside
Options:
-Battery back-up: battery sets (BA16)
-Class 1: earth connection
-Protection class: IP66
-Built-in T Cable device for operating two handsets simultaneously

  Control Boxes

  CB15 (New Product)






CB15 is a multi-function control for ICU bed, it operates with HB16L+C00( Back light series) handset and ACPM41, it has memory, return (CPR) and button lock functions. In order to make more accurate position, CB15 must work with actuators which are equipped with Hall sensor motor.

Features:
- Max. for 4 actuators. Actuator type: LA28, LA31, LA32, LA33, LA35(equipped with Hall sensor motor and 5 cores DIN plug)
- Mains voltage: AC220-240V, 50Hz/ 100-120V, 60Hz
- 100W compact high power toroidal transformer ensures low power consumption and low electromagnetic emission.
- All channels have electronic overload protection (EOP) device.
- DIN socket for HB16L+C00 and ACPM41
- Replaceable straight cable.
- Duty cycle: MAX. 10% or 6 min. continuous use followed by 1 hour not in use.
- Ambient temperature: +5ºC to+ 40ºC
- Protection class: IP54
- Color: Gray-white
- Can be mounted and connected with BA16 or BA18 battery.
- Customized functions (Min. Order 500 pcs)

Options:
- Battery back-up: battery sets BA16 (Lead-Acid battery) or BA18 (Li-ion battery)
- Class 1 earth connection
- Mains fuse can be replaced from outside.
- Protection class: IP66(not allowed being in wash tunnels)
- Color: Black (Min. quantity: 500 PCS)
- Switching power transformer

  Control Boxes

  CB13






CB13 is a low voltage control box that can control up to 4 actuators. A series of built-in safety features and other options make it ideal for electrical and manual dual operation applications.

Features:
-Controls up to 4 actuators; Actuator type: LA27 or LA37 (with Jack Plug)
-Mains voltage: 220-240/ 100-120V AC; 50-60Hz
-Output voltage: Dual output (Low load: Low voltage; High load: High voltage)
-Compact but high power toroidal transformer ensures low power consumption and low electromagnetic emission
-All channels have electronic overload protection (EOP) device
-DIN socket for handset HB3X, HB5X, HB7X, HB8X and ACP
-Fixed type mains cable
-Duty cycle: Max. 10% or 6 min. continuous usage followed by 54 min. rest
-Ambient temperature: +5ºC to +40ºC
-Protection class: IP54
-Color: Black
-Built-in BA16 battery box (batteries excluded)
-"Warning signal"for low battery voltage
-External lock ring to secure all cables
-Mains fuse can be replaced from outside
Options:
-Battery back-up: Battery sets (BA1600)
-Class 1: earthing
-Protection class: IP66
-Built-in T-cable device for operating two handsets simultaneously


  Control Boxes

  CB02






CB02 can operate up to 3 actuators. The simple compact and elegant design makes the control box ideal for use in beds, chairs, tables and other applications; it has remote control function and the competitive price.



Features:

- Connecting up to 3 actuators. Actuator type: LA31, LA32, LA33 (with Jack Plug)
- Compatible with HB8X, HB3X, FS, FLS series
- Elegant design
- Power indicator light
- Mains voltage: 220-240/ 100-120V AC; 50-60HZ
- Output voltage: 24V DC
- 8 PIN DIN-plug for handset
- 1.8m straight cable
- Duty cycle: Max. 5% or 3 min./ 1 hour in continuous use
- Ambient temperature: +5ºC to +40ºC
- Protection class: IP51
- Color: black
- Remote control

Options:

- Protection class: IP66
- Color: Gray-White(Min. order 1,000pcs)
- It can choose Overload function



  Control Boxes

  CB03(NEW)






CB03 can operate up to 3 actuators. Its elegant design is suitable for the use of beds, chairs and tables. It also has a very competitive price.

Features:

-Connect up to 3 actuators; actuators must select 90?DIN Plug
-Can combine with HB3X, HB7X, HB8X series
-Elegant & Lightweight Design
-Main Voltage: 100-240V AC; 50-60HZ (Switching Power Supply)
-Output Voltage: 24V DC
-Use 90?pin Din Plug handset
-1.8 meter in length, straight power cable
-Duty cycle: Max. 10% or 2 min. continuous usage followed by 18 min. rest
-Ambient Temperature:+5ºC to +40ºC
-Can be mounted with actuator LA29
-Color: Black (White Color Optional)
-Protection Class: IP51


  Control Boxes

  CB04






CB04 is an electronic control box. Mainly supply the power to the single actuator. The volume is tiny and will not waste the spare space. Moreover, the cable length can be substituted by the different working environment, and the CB04 is suitable for furniture application.

Features:
-The volume is tiny and space-saving.
-The plug type and the length could be replaced by the existed standards mode.
-The T-plug cable could be extended.
-The actuator plug must be in T plug.
-Power Display Device
-Main voltage:AC 100- 240 1.5A 50-60HZ.
-Output voltage is DC 29 V.
-Output electric current: MAX 2Amp.
-Duty cycle: Max. 10% or 6 mi./1 hour in continuous use.
-Ambient temperature: +5ºC to+ 40ºC
-Production Class:IP51.


  Control Boxes

  CB06






CB06 can operate up to 3 actuators. It has the feature of being mounted with LA33. It has elegant design suitable for the use of beds, chairs, and tables. It is suitable for being installed in less-spaced place and device of single function. It also has features of cheaper price.



Features:

- Max. for 3 actuators. Actuator type: LA33
- Can combine with HB8X, HB3X and FS series to use FLS
- Elegant design
- Power indicator light
- Mains voltage: 220-240/ 100-120V AC; 50-60HZ
- Output voltage: 24V DC
- 8 PIN DIN-plug for handset
- 1.8m straight power cable
- Duty cycle: Max . 5% or 3 min./ 1 hour in continuous use
- Ambient temperature: +5ºC to +40ºC
- Protection class: IP51
- Color: Black

Options:

- Protection class: IP54




  Control Boxes

  CB09






CB09 is a low voltage operated controller for max. 4 actuators. A series of built-in safety and other options makes it ideal for vast medical and industrial applications.

Features:

- Max. for 4 actuators. Actuator type: LA31, LA32, LA33 (with DIN Plug)
- Mains voltage: 220-240/ 100-120V AC; 50-60Hz
- Compact high power toroidal transformer ensures low power consumption and low electromagnetic emission
- Electronic overload protection (EOP) common for all channels
- DIN socket for handset HB8X, HB3X, ACP or FS
- Exchangeable mains cable
- Duty cycle: Max. 10% or 6 min./ 1 hour in continuous use
- Ambient temperature: +5ºC to +40ºC
- Protection class: IP54
- Color: Black
- Can be mounted with BA16
- The Battery has a Warning for low Voltage

Options:

- Battery back-up: battery sets (BA16)
- Class 1: earth connection
- Mains fuse can be replaced from the out-side
- Protection class: IP66
- T-cable device for operating two handsets simultaneously
- Color: Gray White





























































© 2000-2008 CopyRight by Mechatronics Machine Tools Co.,Ltd.
Tel. ติดต่อคุณภูรินทร์ 098-4288648 Email: sales@mechatronics.co.th  Fax. LINE ID : 0984288648  Website. www.mechatronics.co.th
disclaimer | privacy | contact us

  Sale Login Warehouse Login Driver Login
