Product Information :

Product Name:
Torque Sensors
Product Category:   เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Product Sub-Category:   DACELL Loadcell Torque sensor
Brand:   DACELL
Product Type :   สินค้า, ผลิตภัณฑ์
Short Description :   DACELL Torque Sensors



Torque Sensors

Torque sensor on demand. - TRD20-K2

list



Customized torque sensor



Torque sensor on demand. - TRB-30KC

list

Customized torque sensor

Brush type

Option : RPM sensor





qna





Dimensions

 ????_??_TRB37-1A-30KC (???)-Model.jpg



Specifications



SpecificationsAccuracy
Rated capacity(R.C) 30kgf-cm (2.942N-m)
Rated output(R.O) 1mV/V ± 1%
Nonlinearity 0.3% of R.O.
Hysteresis 0.3% of R.O.
Repeatability 0.2% of R.O.
Excitation recommended 10V
Terminal resistance input 350Ω ± 5Ω
Terminal resistance output 350Ω ± 5Ω
Insulation resistance bridge 200 ?
Safe overload 120% R.C.
Cable length φ7, 4core, 3m







? Specifications are subiect to change without notice



Non-rotary torque sensors - TCN23

list

  • Adaptable for portable usage
  • No special adapter tools required
  • Precision repeatable torque measurements
  • Calibration reference for‘hard usage’mechanical torque wrenches

catalog



qna



DIMENSIONS


SPECIFICATIONS

SpecificationsAccuracy
Rated capacity(R.C.)

2 ~ 1000kgf-cm

Rated output(R.O.) 1mV/V ± 1%
Nonlinearity 0.3% of R.O.
Hysteresis 0.3% of R.O.
Reperatability 0.2% of R.O.
Excitation recommended 10V
Terminal resitance, input 350Ω ± 30Ω
Terminal resitance, output 350Ω ± 2Ω
Insulation resistance bridge 300 ?
Temperature range, compensated -10~60?
Temperature range, safe -10~80?
Safe overload 120% R.C.
Cable length φ5, 4core, 5m



CapacityABCDφEFGφHI
2 kgf-cm 58 33 12 4 14 11 11 28 1/4"
5,10 kgf-cm 60 33 13 5.5 16.5 12.5 12 28 3/8"
20,50 kgf-cm 60 33 13 5.5 16.5 12.5 13 28 3/8"
100,200 kgf-cm 71 37 16 7 22 16 17 28 1/2"
500,1000 kgf-cm 98 39 27 14 41.5 29 27 48 1"



Non-rotary torque sensors - TCN16

list

  • A static torque sensor for measurement of torque of stational objects or within a certain angle rotation.
  • Suitable for torque measurement of various automobile parts, pneumatic and electric screwdriver etc.

catalog



qna



DIMENSIONS

SPECIFICATIONS

SpecificationsAccuracy
Rated capacity(R.C.) 2kgf-cm~100kgf-cm (0.196N-m~490.3N-m)
Rated output(R.O.) 1.5mv/v ±1% (2kgf-cm~5kgf-m:1mv/v)
Nonlinearity 0.3% of R.O.
Hysteresis 0.2% of R.O.
Reperatability 0.1% of R.O.
Excitation recommended 10V DC
Temperature range, compensated 0.3% R.O./10?
Temperature range, safe 0.2% LOAD/10?
Safe overload 120% R.O

DIMENSIONS

CapacityABCDEFGHIJK
2kgf-cm (0.196N-m) 63 58 20 34 15 1 8 5 20 4-φ4.5 46
5kgf-cm (0.490N-m) 63 58 20 34 15 1 8 5 20 4-φ4.5 46
10kgf-cm (0.981N-m) 63 58 20 34 15 1 8 5 20 4-φ4.5 46
20kgf-cm (1.961N-m) 63 58 20 34 15 1 8 5 20 4-φ4.5 46
30kgf-cm (2.942N-m) 63 80 20 34 15 1 12 10 40 4-φ6.5 66
50kgf-cm (4.903N-m) 63 80 20 34 15 1 12 10 40 4-φ6.5 66
1kgf-m (9.807N-m) 74 80 21 43 16 5x5 18 10 40 4-φ6.5 66
2kgf-m (19.61N-m) 74 80 21 43 16 5x5 18 10 40 4-φ6.5 66
3kgf-m (29.42N-m) 74 80 21 43 16 5x5 18 10 40 4-φ6.5 66
5kgf-m (49.03N-m) 74 80 21 43 16 5x5 18 10 40 4-φ6.5 66
10kgf-m (98.07N-m) 93 98 35 50 30 10x8 32 15 40 6-φ10.5 78
20kgf-m (196.1N-m) 93 98 35 50 30 10x8 32 15 40 6-φ10.5 78
50kgf-m (490.3N-m) 123 146 55 84 50 12x8 47 20 60 6-φ13 115
100kgf-m (980N-m) 123 146 55 84 50 12x8 47 20 60 6-φ13

115








Non-rotary torque sensors - TCN15

list

  • A static torque sensor for measurement of torque of stational objects of within a certain angle rotation.
  • Suitable for torque measurement of various automobile parts. pneumatic and electric screwdriver etc.

catalog



qna



SPECIFICATIONS

SPECIFICATIONS

SpecificationsAccuracy
Rated capacity(R.C.) 2kgf-cm~100kgf-cm (0.196N-m~490.3N-m)
Rated output(R.O.) 1.5mV/V±1% (2kgf-cm~5kgf-m : 1mV/V)
Nonlinearity 0.3% of R.O.
Hysteresis 0.2% of R.O.
Reperatability 0.1% of R.O.
Excitation recommended 10V DC
Temperature range, compensated 0.3% R.O./10?
Temperature range, safe 0.2% LOAD/10?
Safe overload 120% R.C.

DIMENSIONS

CapacityABCφDEFG
2kgf-cm (0.196N-m) 75 20 35 34 15 1 8
5kgf-cm (0.490N-m) 75 20 35 34 15 1 8
10kgf-cm (0.981N-m) 75 20 35 34 15 1 8
20kgf-cm (1.961N-m) 75 20 35 34 15 1 8
30kgf-cm (2.942N-m) 75 20 35 34 15 1 12
50kgf-cm (4.903N-m) 75 20 35 34 15 1 12
1kgf-m (9.807N-m) 82 21 40 40 16 5x5 18
2kgf-m (19.61N-m) 82 21 40 40 16 5x5 18
3kgf-m (29.42N-m) 82 21 40 43 16 5x5 18
5kgf-m (49.03N-m) 82 21 40 43 16 5x5 18
10kgf-m (98.07N-m) 110 35 40 62 30 10x8 32
20kgf-m (196.1N-m) 110 35 40 62 30 10x8 32
50kgf-m (490.3N-m) 155 55 45 84 50 12x8 47
100kgf-m (980N-m) 155 55 45 84 50 12x8

47







Non-rotary torque sensors - TCN

list

  • A static torque sensor for measurement of torque of stational objects or within a certain angle rotation. Suitable for torque measurement of various automobile parts.
  • Pneumatic and electric screwdriver etc.

catalog



qna



SPECIFICATIONS

SPECIFICATIONS

SpecificationsAccuracy
Rated capacity(R.C.) 2kgf-cm~2000kgf-m (0.196N-m~19.61kN-m)
Rated output(R.O.) 1mV/V±1%
Nonlinearity 0.3% (0.1kgf-m under 0.5% R.O.)
Hysteresis 0.3%(0.1kgf-m under 0.5% R.O.)
Reperatability 0.02% of R.O.
Terminal resitance, input 350Ω ±1%
Terminal resitance, output 350Ω ±1%
Insulation resistance 2000 MΩ
Temperature effect, on zero balance ±0.1% R.O./10?
Temperature effect, on rated output ±0.1% Load/?
Excitation recommended 10V DC
Safe overload 120% R.O
Cable φ5.5 4core cable, 3m

DIMENSIONS

ModelCapacityABCDEφFφGHJφK
TCN-2KC2kgf-cm (0.196N-m) 61 3 55 5 45 20 58 46 33 2x4 - φ4.5
TCN-3KC3kgf-cm (0.294N-m) 61 3 55 5 45 20 58 46 33 2x4 - φ4.5
TCN-5KC5kgf-cm (0.490N-m) 61 3 55 5 45 20 58 46 33 2x4 - φ4.5
TCN-10KC10kgf-cm (0.981N-m) 61 3 55 10 35 40 80 66 48 2x4 - φ6.5
TCN-20KC20kgf-cm (1.961N-m) 61 3 55 10 35 40 80 66 48 2x4 - φ6.5
TCN-30KC30kgf-cm (2.942N-m) 61 3 55 10 35 40 80 66 48 2x4 - φ6.5
TCN-50KC50kgf-cm (4.903N-m) 61 3 55 10 35 40 80 66 48 2x4 - φ6.5
TCN-1K1kgf-m (9.807N-m) 61 3 55 10 35 40 80 66 48 2x4 - φ6.5
TCN-2K2kgf-m (19.61N-m) 61 3 55 10 35 40 80 66 48 2x4 - φ6.5
TCN-3K3kgf-m (29.42N-m) 61 3 55 10 35 40 80 66 48 2x4 - φ6.5
TCN-5K5kgf-m (49.03N-m) 61 3 55 10 35 40 80 66 48 2x4 - φ6.5
TCN-10K10kgf-m (98.07N-m) 61 3 55 10 35 40 80 66 48 2x4 - φ6.5
TCN-20K20kgf-m (196.1N-m) 86 3 80 15 50 40 98 78 48 2x6 - φ10.5
TCN-50K50kgf-m (490.3N-m) 130 3 124 20 84 60 118 95 68 2x6 - φ10.5
TCN-100K100kgf-m (980N-m) 136 3 130 20 90 60 146 115 75 2x6 - φ13
TCN-200K200kgf-m (1.961KN-m) 146 3 140 25 90 60 166 130 99 2x8 - φ17
TCN-500K500kgf-m (4.903KN-m) 176 3 170 35 100 60 197 155 98 2x12 - φ17
TCN-1000K1000kgf-m (9.807KN-m) 180 3 174 37 100 90 248 180 110 2x12 - φ21
TCN-2000K2000kgf-m (19.61KN-m) 180 3 174 37 100 90 248 180 128

2x12 - φ21








Rotary Torque sensors - TRS

list

  • TRS socket wrench torque sensors are used for fast, accurate measurement of bolt or nut wrenching torque. This model operates in both directions sotightening and break-away torques can be measured.
  • It can also be used to check the calibration of mechanical torque wrenches.

catalog



qna



DIMENSIONS

SPECIFICATIONS

SpecificationsAccuracy
Rated capacity(R.C.) 2kgf-cm~3000kgf-cm (0.196N-m~294.2N-m)
Rated output(R.O.) 1.3mV/V
Nonlinearity 0.3%R.O
Hysteresis 0.3%R.O
Reperatability 0.3%R.O
Terminal resitance, input 350±3Ω
Terminal resitance, output 350±3Ω
Insulation resistance 300?
Temperature range, compensated -10?~60?
Temperature range, safe -20?~70?
Safe overload 150%R.C
Excitation recommended 10V DC
Temperature effect, on zero balance 0.05%R.O/10?
Temperature effect, on rated output 0.1% Load/10?
Excitation recommended 10V DC
Safe overload 150%R.C
Cable length φ4 Shield 3m


Rotary Torque sensors - TRE

list

  • Model TRE slipring rotating torque transducers have flange drives at both ends. This model is designed for the application with minmal space and high capacity requirement.

catalog



qna



DIMENSIONS

SPECIFICATIONS

SpecificationsAccuracy
Rated capacity 20kgf~500kgf-m (196.1N-m~4.903kN-m)
Rated output 1.5mV/V
Nonlinearity 0.3%
Hysteresis 0.3%
Reperatability 0.3%
Terminal resitance, input 350Ω ± 5%
Terminal resitance, output 350Ω ± 3%
Insulation resistance 300?
Temperature range compensated -10~60?
Temperature range safe -20~70?
Temperature effect, on zero balance 0.3% R.O / 10?
Temperature effect, on rated output 0.2% Load / 10?
Excitation recommended 10V DC
Safe overload 150% R.C
Cable φ7 Shield 3m

DIMENSIONS

unit:mm

ModelCapacityABCφDφEφFφGHIJKLPR.P.M
TRE-20K20kgf-m
(196.1N-m)
130 98 12 65 52 127 81 38 6-φ6.5 40 64 105 M6DP8 5,000
TRE-50K50kgf-m
(490.3N-m)
134 102 12 76 62 136 88 41.5 6-φ8.5 40 64 114 M6DP8 4,000
TRE-100K100kgf-m
(980.7N-m)
134 102 12 86 68 156 100 48 8-φ10.5 48 64 130 M8DP8 4,000
TRE-200K200kgf-m
(1.961KN-m)
148 108 16 102 75 172 116 56 8-φ10.5 50 68 146 M8DP8 3,000
TRE-300K300kgf-m
(2.942KN-m)
148 108 16 102 75 172 116 56 8-φ10.5 50 68 146 M8DP8 3,000
TRE-500K500kgf-m
(4.903KN-m)
150 102 16 107 81 184 128 62 8-φ10.5 56 74 158 M8DP8 3,000






DIMENSIONS

unit:mm

ModelSocket SizeABCDφEFGMKLJH
2, 5, 10kgf-cm
(0.196N-m, 0.490N-m, 0.980N-m)
1/4? 76 52 12 4 15 10 6.35 25 50 11 34 41
20, 50kgf-cm
(1.961N-m, 4.903N-m)
3/8? 82 56 12 4 15 12.5 9.53 25 50 13 34 41
100, 300kgf-cm
(9.807N-m, 29.42N-m)
1/2? 96 58.5 19.5 7 20 16 12.7 31 62 17 44 42
500, 1000kgf-cm
(49.03N-m, 98.07N-m)
3/4? 106 58 24 10 30 22 19.1 34 68 22 52 53
2000, 3000kgf-cm
(196.12N-m, 294.20N-m)
1? 123 58 33 14 40 29.2 25.4 39 78 28 62 54

Rotary Torque sensors - TRD

list

  • Model TRD loadcell measure the torque of continuous rotating object. Platinum coated connector provides long term signal stability and high accuracy.
  • These models are most appropriate for industrial measurement. Applications include the performance testers for automotive components such as clutchs, transmissions, motors and pumps.
  • Option : Foot mount

catalog



qna



DIMENSIONS

SPECIFICATIONS

SpecificationsAccuracy
Rated capacity(R.C) 2, 5, 10, 20, 30, 50(kgt-cm)
1, 2, 3, 5, 10, 20,50, 100, 200, 500, 1000, 2000(kgf-m)
0.196, 0.490, 0.981, 1.961, 2.942, 4.903, 9.807, 19.61,
29.42, 49.03, 98.07, 196.1, 490.3, 980.7(N-m)
1.961,4.903, 9.807, 19.61(kN-m)
Rated output(R.O) 1.5mV/V±1%(2?f-cm~5kgf-m:1mV/V)
Nonlinearity 0.3% R.O.
Hysteresis 0.3% R.O.
Reperatability 0.2% R.O.
Excitation recommended 10 VA
Terminal resistance 350Ω±5%
Insulation resistance bridge 200?
Temperature effect, on rated output 0.2% Load / 10?
Temperature effect, on zero balance 0.3% R.O / 10?
Safe overload 120% R.C
Cable length φ7.4core coble 3m

DIMENSIONS

unit:mm

ModelCapacityABCDEFφGφHIJKφLMRR.P.M
TRD-2KC2kgf-cm
(0.196N-m)
84 16 52 12 42 32 8 60 34 65 76 5.5 8 1 3000
TRD-5KC5kgf-cm
(0.490N-m)
84 16 52 12 42 32 8 60 34 65 76 5.5 8 1 3000
TRD-10KC10kgf-cm
(0.981N-m)
84 16 52 12 42 32 8 60 34 65 76 5.5 8 1 3000
TRD-20KC20kgf-cm
(1.961N-m)
84 16 52 12 42 32 8 60 34 65 76 5.5 8 1 3000
TRD-30KC30kgf-cm
(2.942N-m)
84 16 52 12 42 32 12 60 34 65 76 5.5 8 1.5 3000
TRD-50KC50kgf-cm
(4.903N-m)
84 16 52 12 42 32 12 60 34 65 76 5.5 8 1.5 3000
TRD-1K1kgf-m
(9.807N-m)
90 16 58 12 46 32 18 72 41 80 94 6.5 8.5 5x5 5000
TRD-2K2kgf-m
(19.61N-m)
90 16 58 12 46 32 18 72 41 80 94 6.5 8.5 5x5 5000
TRD-3K3kgf-m
(29.42N-m)
90 16 58 12 46 32 18 72 41 80 94 6.5 8.5 5x5 5000
TRD-5K5kgf-m
(49.03N-m)
180 42.5 95 35 64 50 18 80 46 80 100 7 12 5x5 5000
TRD-10K10kgf-m
(98.07N-m)
180 42.5 95 35 64 50 18 80 46 80 100 7 12 5x5 5000
TRD-20K20kgf-m
(196.1N-m)
220 55 110 45 100 84 32 100 63 98 115 7 12 10x8 4000
TRD-50K50kgf-m
(490.3N-m)
220 55 110 45 100 84 32 100 63 98 115 7 12 10x8 4000
TRD-100K100kgf-m
(980N-m)
280 80 120 69 120 98 47 100 66 124 148 8.5 15 12x8 4000
TRD-200K200kgf-m
(1.961KN-m)
280 80 120 69 120 98 47 100 66 124 148 8.5 15 12x8 4000
TRD-500K500kgf-m
(4.903KN-m)
390 130 130 100 126 100 90 172 101 154 180 11 20 25x14 2000
TRD-1000K1000kgf-m
(9.807KN-m)
390 130 130 100 126 100 90 172 101 154 180 11 20 25x14 2000
TRD-2000K2000kgf-m
(19.61KN-m)
440 150 140 120 148 110 115 210 130 190 228 13 23 32x18 2000


Rotary Torque sensors - TRC

list

  • Model TRC brushless type torque transducers are designed for high RPM application.
  • The brushless type allows a maintenance free and a maximum durability.
  • This model can be used for various tests including aircraft engine test which requires high RPM and high accuracy.
  • Option : r.p.m. sensor, Foot mount.

catalog



qna



DIMENSIONS

SPECIFICATIONS

SpecificationsAccuracy
Rated capacity(R.C) 1, 2, 5, 10, 20, 50, 100, 200, 500, 1000, 2000(kgf-m), 9.807, 19.61,
49.03, 98.07, 196.1, 490.3, 980.7(N-m) 1.961, 4.903, 9.807, 19.61(kN-m)
Rated output(R.O) 1.3mV/V±1%
Nonlinearity ±0.5% R.O.
Hysteresis ±0.5% R.O.
Reperatability ±0.5% R.O.
Excitation recommended 2 VAC
Temperature operating 0 ~60?
Insulation resistance bridge 0.2% Load / 10?
Temperature effect, on rated output 0.3% R.O / 10?
Temperature effect, on zero balance 120% R.C
Safe overload φ7.4 core cable 3m
Cable length cable φ10, 4core shield 5m

DIMENSIONS

ModelCapacityABCφDφEFGIMNOφPQRR.P.MWeight
(kg)
TRC-1K1kgf-m
(9.807N-m)
236 146 45 84 17 40 5x5 55 12 83 101 7 91 109 10,000 3
TRC-2K2kgf-m
(19.61N-m)
236 146 45 84 17 40 5x5 55 12 83 101 7 91 109 10,000
TRC-5K5kgf-m
(49.03N-m)
236 146 45 84 17 40 5x5 55 12 83 101 7 91 109 10,000
TRC-10K10kgf-m
(98.07N-m)
240 150 45 90 25 40 8x7 60 12 83 101 7 97 115 10,000 8
TRC-20K20kgf-m
(196.1N-m)
240 150 45 90 25 40 8x7 60 12 83 101 7 97 115 10,000
TRC-50K50kgf-m
(490.3N-m)
302 162 70 114 45 60 10x8 75 15 97 121 9 123 147 8,000 15
TRC-100K100kgf-m
(980.7N-m)
302 162 70 114 45 60 10x8 75 15 97 121 9 123 147 8,000
TRC-200K200kgf-m
(1.961KN-m)
336 176 80 148 70 70 18x11 95 20 97 121 9 157 181 5,000 25
TRC-500K500kgf-m
(4.903KN-m)
336 176 80 148 70 70 18x11 95 20 97 121 9 157 181 5,000
TRC-1000K1000kgf-m
(9.807KN-m)
445 185 130 173 90 110 25x14 110 20 108 134 11 184 210 3,800 55
TRC-2000K2000kgf-m
(19.61KN-m)
513 193 160 203 110 140 28x16 128 23 121 159 13 216 254 3,000 110


Rotary Torque sensors - TRB

list

  • Model TRB load cell measure the torque of continuous rotation object.
  • Platinum coated connector provides long term signal stability and high accuracy.
  • These models are most appropriate for industrial measurement.
  • Applications indlude the performance testers for automotive components such as clutchs,transmissions, motors and pump.

catalog



qna



SPECIFICATIONS

SPECIFICATIONS

SpecificationsAccuracy
Rated capacity(R.C.) 1~2000?f-m
(9.807N-m~19.61kN-m)
Rated output(R.O.) 1.5mV/V±1%(1~5?f-m:1mV/V)
Nonlinearity 0.3%R.O
Hysteresis 0.2%R.O
Repeatability 0.3%R.O.
Excitation recommended 10V
Terminal resistance 350 Ω ±5%
Insulation resistance bridge 200 ?
Temperature effect, on rated output 0.2% Load/10 C
Temperature effect, on zero balance 0.3% R.O./10 C
Safe overload 120% R.O
Cable length φ7.4 core cable 3m

DIMENSIONS

ModelCapacityABCDEFφGφHIJKφLMRR.P.MWeight
(kg)
TRB-1K1kgf-m
(9.807N-m)
191 43 105 38 68 50 18 72 41 72 86 7 8.5 5x5 5000 3
TRB-2K2kgf-m
(19.61N-m)
191 43 105 38 68 50 18 72 41 72 86 7 8.5 5x5 5000 3
TRB-5K5kgf-m
(49.03N-m)
191 43 105 38 68 50 18 72 41 72 86 7 8.5 5x5 5000 3
TRB-10K10kgf-m
(98.07N-m)
260 55 150 40 100 84 32 100 63 98 115 7 12 10x8 5000 7
TRB-20K20kgf-m
(196.1N-m)
260 55 150 40 100 84 32 100 63 98 115 7 12 10x8 4000 7
TRB-50K50kgf-m
(490.3N-m)
310 80 150 70 120 98 47 118 75 124 148 9 15 12x8 4000 12
TRB-100K100kgf-m
(980.7N-m)
310 80 150 75 120 98 47 118 75 124 148 9 15 12x8 4000 12
TRB-200K200kgf-m
(1.961KN-m)
375 100 175 85 120 98 63 135 90 150 180 10.5 20 18x11 4000 25
TRB-300K300kgf-m
(2.942KN-m)
375 100 175 95 120 98 63 135 90 150 180 10.5 20 18x11 3000 25
TRB-500K500kgf-m
(4.903kN-m)
500 140 220 115 148 118 90 170 114 162 192 11 26 25X14 3000 55
TRB-1000k1000kgf-m
(9.807kN-m)
500 140 220 115 148 118 90 170 114 162 192 11 26 25X14 3000 55
TRB-2000k2000kgf-m
(19.61kN-m)
680 208 264 160 210 172 115 210 138 190 230 13 26 32X18 3000 110

Rotary Torque sensors - TRA

list

  • Model TRA load cell measure the torque of continuous rotatin object.
  • Platinum coated connector provides long term signal stability and high accuracy.
  • These models are most appropriate for industrial measurement.
  • Applications Include   the performance tester for automotive components such as clutchs, transmissions, motors and pumps.
  • Option :  Foot mount.

catalog



qna



SPECIFICATIONS

DIMENSIONS TABLE

SpecificationsAccuracy
Rated capacity(R.C) 1~300?f-m
(9.807N-m~2.942kNm)
Rated output(R.O) 1.5mV/V±1%(1~5?f-m:1mV/V)
Nonlinearity 0.3%R.O.
Hysteresis 0.2%R.O.
Reperatability 0.3%R.O.
Excitation recommended 10V
Terminal resistance 350Ω±1%
Insulation resistance bridge 200?
Temperature effect, on rated output

Non-rotary torque sensors

Torque sensor on demand.

Torque transducer_TRD20-K2

TRD20-K2



Torque sensor on demand. - TRB-30KC

list

Customized torque sensor

Brush type

Option : RPM sensor





qna





Dimensions

 ????_??_TRB37-1A-30KC (???)-Model.jpg



Specifications



SpecificationsAccuracy
Rated capacity(R.C) 30kgf-cm (2.942N-m)
Rated output(R.O) 1mV/V ± 1%
Nonlinearity 0.3% of R.O.
Hysteresis 0.3% of R.O.
Repeatability 0.2% of R.O.
Excitation recommended 10V
Terminal resistance input 350Ω ± 5Ω
Terminal resistance output 350Ω ± 5Ω
Insulation resistance bridge 200 ?
Safe overload 120% R.C.
Cable length φ7, 4core, 3m





© 2000-2008 CopyRight by Mechatronics Machine Tools Co.,Ltd.
Tel. ติดต่อคุณภูรินทร์ 098-4288648 Email: sales@mechatronics.co.th  Fax. 038-111360  Website. www.mechatronics.co.th
disclaimer | privacy | contact us

  Sale Login Warehouse Login Driver Login
